Specifications
| Object of measurement | Conductivity of liquids or solutions |
| Measuring principle | Two-electrode system |
| Cell constant | ۰٫۰۵ cm-1, 5 cm-1 |
| Measuring range | ۰-۰٫۵ to 0-200 μS/cm (Cell constant: 0.05 cm-1) ۰-۲۰۰ μS/cm to 0-20 mS/cm (Cell constant: 5 cm-1) |
| Temperature Range | ۰ to 105 deg C (chamber material: SCS14) ۰ to 100 deg C (chamber material: Polypropylene) |
| Pressure range | ۰ to 1 MPa (chamber material: SCS14) ۰ to 500 kPa(chamber material: Polypropylene) |
| Measuring solution condition | Flow rate: less than 20 l/min is recommended for flow-through type. Air bubbles should not be mixed in the sample solutions to obtain correct measured values. |
| Temperature sensor | PB36 NTC |
| Construction | JIS C0920 watertight (equivalent to NEMA4) |
| Process connection | Screw-in, Flange, Flow-through, with gate valve |
